MWC22 Barcelona - Assessment of Roaming AUDIO MOS Performance Testing

Updated: Nov 22

In the last few years, there are many discussions across the world regarding the 2G/3G Network sunset/shutdown. Many operators have either already shut down their 2G/3G or are planning to in the near future.


The drivers behind this move are several with the main ones re-using frequencies to newer technologies like 4G and 5G and reducing costs and effort in maintaining legacy radio networks.



This move will affect end-users in a variety of ways and during this year’s Mobile World Congress in Barcelona SmartViser assessed the true impact of this change. We have performed testing at the event of the Audio MOS quality on different radio networks and using WhatsApp. At the time of the event (28/02/22 – 03/03/22), there were no roaming VoLTE agreements for the networks we have checked VDF UK, O2 UK, Orange FR.


The map below gives an overview of the VoLTE roaming agreements per country and there are none in place for Spain.




Source: GSMA (https://www.gsma.com/aboutus/workinggroups/key-areas/volte-roaming)




Testing Configuration


Testing was conducted at the event with an Orange France SIM roaming on the Orange Spain network. The device used was an LG Velvet. All testing was performed calling a Samsung A52 with an SFR France SIM roaming on the Movistar network.

viSer test automation was used to ensure all the KPIs are collected, reliability and repeatability of the testing. Together with ViSer test automation the add on viSer Audio MOS solution using the POLQA algorithm was also used for the accurate measurement of the audio quality.


Test Sets:

1) Cellular Calls 2G

2) Cellular Calls 3G

3) WhatsApp Calls on 4G Network


The Network condition was very good:

  • 2G (Blue): RxLev ~ -55 dBm

  • 3G (Black): RSCP ~ -60 dBm

  • 4G (Green): RSRP ~ -75 dBm


The diagram below shows the signal strength and timeline.



Testing Results


The average Audio MOS score was a surprise, with a big difference between each option.

  • 2G Cellular calls had an average score of 2.85* (Blue)

  • 3G Cellular Calls had an average score of 3.04* (Black)

  • WhatsApp Calls using a 4G network had an average score of 4.05* (Green)



*POLQA™ MOS scores:

  • Score 1: means that despite great effort, it is impossible to understand what is being said during the call (the call repeatedly cuts in and out)

  • Score 2: means the quality is not good and a lot of effort is needed to understand

  • Score 3: indicates an acceptable level of quality and fairly understandable conversation

  • Score 4: is a good quality level, understandable with minor interference noise

  • Score 5: is an excellent quality level, understandable discussion without interference noise


WhatsApp call used an average bandwidth of 14 kbps:




Performance Testing Conclusion


The results collected from our team show that it is imperative for the industry to prepare fully for the 2G/3G network shutdowns.


It will be important to educate and encourage end-users to upgrade their devices to VoLTE/VoWiFi capable and Mobile Network operators will need to significantly accelerate the VoLTE roaming agreements across the world.


Covid has played a significant role in slowing the progress of putting these agreements in place as roaming traffic had almost disappeared during the lockdowns. The rate of network shutdowns though continued as planned and there is now this gap in Quality of Experience (QoE) that need to be addressed.


As Tommy Ljunggren from Telia Company has highlighted the necessity for action:

“My recommendation to the Operators is to get going now and start with the first roaming agreements, first roaming implementations, because when you have done the first you will learn so much that you can very quickly go to the second, the third, the fourth”


For business users travelling to Spain for the Mobile World Congress in 2022 WhatsApp calls and potentially other OTT apps were the best option over cellular calls.


For end-users whose device does not support VoLTE or if they are using a feature phone then the cellular audio MOS calls are expected to be of poor or average quality. Especially in countries/networks where 3G is already switched off the only option will be 2G calls and from our experience in Barcelona, a lot of effort is required to understand the conversation.


For the latest list on 2G/3G network shutdown please check: https://www.smartviser.com/post/2g-3gnetworkshutdown



GSMA has created a toolkit to address known VoLTE roaming issues and also provide a summary of industry plans to decommission 2G/3G networks. The very useful toolkit can be found: https://www.gsma.com/aboutus/workinggroups/key-areas/volte-roaming
